Understanding Local Contrast Enhancement

A Photoshop Technique

Digital image processing is still new enough for most people that no matter how much we read, experiment and work at it, there seems to be an endless amount to learn. This is particularly true as regards Photoshop, that invaluable tool yet also bottomless pit of a time sink. But every now and then a little tidbit comes along that makes ones work either easier or better, and this one, which I call Local Contrast Enhancement — is one of the best that I've seen in a while.

I learned of it from Thomas Knoll, a member of a couple of my workshops during 2003, and not-incidently, the original author of Adobe Photoshop and Camera RAW. Thomas says that he certainly didn't develop the technique, but I haven't yet seen or read about it anywhere else, though it appears to have been around for a while. (Below are links to sites contain this and similar techniques that have been brought to my attention since first publication).


Grasses. Mt. Whitney — May, 2003
Canon 1Ds with 28-70mm f/2.8L @ ISO 400

The Problem

The real world has a much greater dynamic range than does a photographic print. By this I'm referring to the range of brightness encountered — from the brightest non-specular highlights in a scene to the deepest shadows. This can be as much as 8 stops, while a typical print on, say, matte paper may only be able to display a 5.5 stops range.

Trying to stuff 8 stops into 5.5 stops means that something has to give, and invariably it's the shadow areas. They'll likely be completely lost in a sea of black. But if you try and match the scene's black level to that of the print you'll end up reducing the contrast of the image across the entire dynamic range.

One solution is to apply an S-Curve to the image, where you compress the dynamic range both in the highlights and in the shadows so as to provide a greater percentage of the available dynamic range to the mid-tones to which the human eye is more sensitive. But if you do this, while you end up with images containing enough mid-tone contrast, they may lack tonal detail in the shadows and highlights.

The Solution — Yes, sometimes there is a free lunch.


Crofts and Waterfall. Iceland — July, 2003
Canon 1Ds with 70-200mm f/2.8L IS lens @ ISO 200
Detail — prior to Local Contrast Enhancement
Detail — after Local Contrast Enhancement

There is a simple yet elegant fix for this, and surprisingly it is done by using the Unsharp Mask filter. Here’s how to do it, and why it works…

Think about the way that the eye takes in a wide dynamic range scene. As we look at it we are constantly jumping from area to area, and as we do so our eyes are adapting to the brightness requirements of the subject. Without going into the physiology of it, this is indeed happening at a more fundamental level than simply the eye’s iris opening and closing.

It turns out though that the eye and brain care more about small scale contrast than large scale contrast. Large scale contrast is that between significant light and dark areas in the image. Small scale or "local contrast" is that between much smaller adjacent areas in the image. Improve this and you've made the shadow and highlight areas (where contrast is most compressed) appear broader.

Try the following setting using the Unsharp Mask filter in Photoshop:

Amount — 20%

Radius — 50

Threshold — 0

The Radius setting is the dividing line between the small scale and large scale contrast differences. Amount is the amount by which you are increasing the small scale differences, and the Threshold is set at zero to minimize artifacts. (This is done as a seperate step from whetever settings you may use within Unsharp Mask for your normal image sharpening).

That's it. Try it. Try changing Radius and Amount to see what differences this makes. Use Undo or the History Palette to jump backwards and forwards to see what the effect does. Look at images on-screen at 100% as well as filling the screen. Make prints with and without.

Note that this is a subtle effect. Don't expect it jump out and bite you. You wouldn't want this in any event. But when you look at prints side by side, with and without, I think you'll be amazed as well as pleased with the results.

Thanks Thomas!

Similar Approaches

Here's a link featuring the same concept.

And another (see the bottom of the page).
